Product name : 2500-2700MHz Grid Parabolic Antenna 18dBi
Product No. : DT-GPA2500-2700-18
←[Previous Product]
Online Inquiry         Email Us

  Details:



ELECTRICAL
Model DT-GPA2500-2700-18
Frequency Range 2500-2700MHz
Gain 18dBi
Beamwidth H: 13° , E: 16°
VSWR ≤1.5
F/B Ratio ≥25dB
Polarization Vertical
Max Power 50W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension          300*400mm
Weight 1.5kg
Mounting Kits L Bracket & U Bolts
Working Temperature -40 ~ + 60
Rated Wind Velocity                              60m/s
