Products > WLan WiFi Antennas > 2.4GHz Panel Antenna > 2300-2700MHz WIFI Panel Antenna 14dBi
Product name : 2300-2700MHz WIFI Panel Antenna 14dBi
Product No. : DT-PA2300-2700-14
             [Next Product]→
Online Inquiry         Email Us

  Details:



ELECTRICAL
Model DT-PA2300-2700-14
Frequency Range 2300-2700MHz
Gain 14dBi
Beamwidth H: 65° , E: 50°
VSWR ≤1.5
F/B Ratio ≥20dB
Polarization Vertical
Max Power 50W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female *2 or customized
Antenna Dimension          190*190*40mm
Weight 1kg
Antenna Color White
Diameter of the Pole Φ40-55mm
Working Temperature -40-+65℃
Rated Wind Velocity                             60m/s
