Product name : 2.4GHz Panel Antenna 18dBi
Product No. : DT-PA2400-18
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:



ELECTRICAL
Model DT-PA2400-18
Frequency Range 2400-2500MHz
Gain 18dBi
Beamwidth H: 17° , E: 17°
VSWR ≤1.5
F/B Ratio ≥25dB
Polarization Vertical
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension          365*365*35mm
Weight 2kg
Diameter of the Pole Ф35-55mm
Mounting Kits L Bracket & U Bolts
Working Temperature -40-+60
Rated Wind Velocity                              60m/s
