Shenzhen Deertom Technology Co.,Ltd

Products > WLan WiFi Antennas > 2.4GHz Panel Antenna > 2.4GHz WIFI Sector Antenna 90 Degrees 16dBi
Product name : 2.4GHz WIFI Sector Antenna 90 Degrees 16dBi
Product No. : DT-SPA2400-16-90
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:



ELECTRICAL
Model DT-SPA2400-16-90
Frequency Range 2400-2500MHz
Gain 16dBi
Beamwidth H: 90° , E:
VSWR ≤1.5
F/B Ratio ≥20dB
Polarization Vertical
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension          950*180*65mm
Weight 4.5kg
Radome Material UPVC
Diameter of the Pole Φ50-105mm
Rated Wind Velocity 60m/s
Connector Position                         Bottom
