Product name : 5150-5850MHz Dual Polarization Panel Antenna 22dBi
Product No. : DT-PA5158-22-2
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:



ELECTRICAL
Model DT-PA5158-22-2
Frequency Range 5150-5850MHz
Gain 22*2dBi
Beamwidth H: 17° , E: 17°
VSWR ≤1.5
F/B Ratio ≥25dB
Polarization Vertical and Horizontal or ±45°
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female *2 or customized
Antenna Dimension          365*365*35mm
Weight 2kg
Diameter of the Pole Ф35-55mm
Mounting Kits L Bracket & U Bolts
Working Temperature -40-+60
Rated Wind Velocity                              60m/s
