Product name : 2500-2700MHz Panel Antenna 18dBi
Product No. : DT-PA2500-2700-18
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:




ELECTRICAL
Model DT-PA2500-2700-18
Frequency Range 2500-2700MHz
Gain 18dBi
Beamwidth H: 22° , E: 20°
VSWR ≤1.5
F/B Ratio ≥25dB
Polarization Vertical
Max Power 50W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension          365*365*35mm
Weight 2kg
Mounting Kits L Bracket & U Bolts
Working Temperature -40 ~ + 60
Rated Wind Velocity                             60m/s
